Fixed Wing Recovery Bundle – 113lbs (51Kg) @ 15fps

$1,549.90

The bundle includes everything needed to recover a fixed wing aircraft with a weight of up to 113lbs (51Kg) @ 15fps (4.6m/s).

SKU: FWRB-192-S-4P Categories: , Tags: , , , , ,

Select Harness Mount: *

View cart

Description

Fixed Wing Recovery Bundle

This bundle assumes the UAV is in forward flight for deployment. Put the recovery gear below a hatch. When the hatch open the airflow will quickly fetch the pilot chute, and that in turn drags the main parachute out. Choose the bundle based on your UAV weight. Systems are rated at 15fps max descent speed.

Bundle Includes

  • IFC-192-S Iris Ultra Compact Chute with Spectra shroud lines
  • CDB-75, 14″L Deployment Bag
  • CFC-36 Classic Elliptical pilot chute
  • Y harness to provide a 4 point mount to your UAV at the Cg.
  • 9/16″ Nylon Webbing shock cord, 6 yards length
  • 3/8″ Nylon Webbing to attach the pilot chute to the deployment bag, 2.5 yards length
  • Quick links to attach the components together.
  • Estimated System Weight – 2250g
  • Estimated Packing Volume – 500 cu”

NOTE: Lead time for this product is about 2 weeks to ship ARO. Contact us if your timeline is tight and we can let you know what the current lead time is at.

Download the Fixed Wing Recovery Bundle Users Guide

IMPORTANT: Our product is 100% made in the USA, and 100% US materials. It is not mass-produced in China or somewhere else. The quality of the materials are very high! In most cases the lead time from order to ship date for recovery bundles is about 4 weeks. If you need something faster please contact us first so we can do a stock check and let you know what we can do.

Thank you for your patience!
