MT2208 Motor

$43.90

MT2208 by Tiger Motors is a high-performance, brushless motor designed for use on multi-rotor aircraft such as quadcopters and hexacopters.

On average, T-motor product ships 3-5 days from purchase.
Contact us for rush delivery requests.

Availability: Out of stock SKU: MT2208 Categories: , Tags: , , , , , , , ,

Description

MT2208 by Tiger Motors is a high-performance, brushless motor designed for use on multi-rotor aircraft such as quadcopters and hexacopters. It is designed to operate smoothly and be well balanced directly out of the box. The MT2208 is part of Tiger Motor MT Series – Professional line of motors.

mt2208_drawing

 MT2208 Features

  • Precision workmanship
  • Smooth running
  • Well-balanced
  • EZO Bearings

MT2208 is outfitted with EZO Bearings to ensure it is smooth running and well balanced right out of the box. The design also cuts down on vibrations that negatively affect aerial video and autopilot inertial sensors. Motor has epoxy-coated Kawasaki stator plates for low eddy current loss, oxygen-free copper windings for low resistance, and N45UH high-temperature Neodymium magnets.

This highly efficient motor can maintain good performance up to 180° C. Backed by a two-year manufacturer’s warranty on materials and workmanship.

MT2208 Recommended for use with 3 to 4S LiPo and 8×2.7 to 11×3.7 props.



About Tiger Motors (T-Motor)

Tiger Motors specializes in manufacturing motors, esc, propellers and other related UAV products. Tiger Motors aims to provide the safest propulsion system for commercial and professional applications. Tiger Motors has a strong R & D team who have a passion for innovation.

MT2208
KV 1100
Configuration 12N14P
Stator Diameter 22mm
Stator Length 8mm
Shaft Diameter 3.175mm
Motor Dimensions (Dia x Len) 27.5 x 24.5mm
Weight (g) 45g
Idle current (10)@10v(A) 0.1A
No. of Cells (Lipo) 3-4S
Max Continuous current (A) 180S 12A
Max Continuous power (W) 180S 180W
Max. efficiency current (2-6)>80%
Internal resistance 165m
Cable 400mm 3.5mm connector

mt2208_specs
