700_CSH

7″ LED LCD Monitor w/ HDMI, DVI, VGA & AV Inputs

$279.00

7″ LED LCD Monitor w/ HDMI, DVI, VGA & AV Inputs by Xenarc Technologies. The unit incorporates our latest LED backlight technology for increased brightness and has an ambient light sensor which dims the backlight automatically when required.

SKU: 700YH Categories: , Tags: , , , , , , , ,

Touch Panel Type *

Choose Your Touch Panel

View cart

Description

7″ LED LCD Monitor w/ HDMI, DVI, VGA & AV Inputs by Xenarc Technologies. The unit incorporates our latest LED backlight technology for increased brightness and has an ambient light sensor which dims the backlight automatically when required. In addition, Chip Monolithic Ceramic Capacitors are used though out the unit for improved stability and durability especially in extreme temperature conditions.

Don’t mistake this display for an ordinary video monitor. This 7″ monitor has 800 x 480 pixels (2400 x 480 sub-pixels) that help display crystal clear text and ultra-sharp images through your computer’s VGA, DVI, or HDMI ports or your Blu-Ray player’s HDMI signal.

These displays come with an instruction manual, a copper monitor stand, a stylus, an AC adaptor, a connection cable, a DVI to HDMI adaptor, and a cigarette lighter car adaptor .

Features

  • For In-Car Computing, PC, Server, GPS, and various VGA, HDMI, and DVI Use
  • High Bright LCD Panel with LED Backlight
  • HDMI Input x 1, VGA Input (15 pin D-SUB) x 1 & Video Input x 2
  • DVI Input through included DVI to HDMI adaptor
  • Supports HDCP
  • Audio Input x 3 / Built-in Speaker
  • NTSC / PAL Multi-System
  • 16×9 Aspect Ratio
  • High Resolution Display
  • Auto detects 800×480 resolution
  • Upgraded High-Brightness LED Backlight
  • Chip Monolithic Ceramic Capacitors for improved durability
  • Automatic backlight level adjustment through built-in ambient light sensor
  • Pixelworks High Performance Image and Video Signal Processor
  • AISS – Advanced Image-Scaling and Shaping
  • 16:9 / 4:3 Scaler settings
  • Last Input memory
  • Last Power setting memory
  • IR Remote Control
  • Auto power-on upon signal detection
  • Automatic display adjustment
  • On Screen Display Control
  • Mirror Image Flip
  • Vertical Image Flip
  • Function to disable front button(s)
  • Function to disable On Screen Text
  • AV2 Auto Switching for backup camera
  • Copper Stand: 360° / Height Adjustment
  • VESA 50mm mounting holes
  • 26-Pin heavy-duty connector
  • Anti Glare Coating
  • Supports 10V DC ~ 35V DC
  • “E” Mark Certified for Automotive use
  • Supports 10V DC ~ 35V DC
  • “E” Mark Certified for Automotive use

Why do our products outlast others in extreme conditions?  Why do our products have a wider temperature range and a wider voltage input range?  It is because our mission is to offer our customers the best products for any situation.  By utilizing high grade components, this display is perfect for industrial, in-car computing applications or any other applications where a small, durable, light weight, high brightness display is required.

Package Contents

  • Copper Monitor Stand
  • AC Adaptor or Cigarette Lighter Car Adaptor or 5M Power Lead
  • 1.8M Connection Cable (5M version available separately)
YH_series

About Xenarc

Xenarc Technologies Corp. fills in the gaps in its high brightness product line with a 9” LED LCD display with a brightness rating of 1,000NITs.  The high brightness of this monitor makes it ideal for outdoor applications under direct sunlight, as well as any other applications where a bright, non-reflective display may be effective.

  • Screen Size:  Diagonal 7″  (16:9)
  • Physical Resolution: 800 (H)  x 480 (V) WVGA
  • Supported PC Resolution:  640 x 480 ~ 1920 x 1080
  • Supported HDMI video Signal: 480i, 480p, 720i, 720p, 1080i, 1080p
  • Dot Resolution: 2400 x 480 = 1,152,000 (dots)
  • Brightness: 600 cd/m²
  • Contrast Ratio: 700:1
  • Viewing Angle: 140° Horizontal, 120° Vertical
  • Response Time (Tr/Tf): 10/15ms (Typ.)
  • Operating Voltage Range: DC 10V ~ 35V
  • Power Supply: DC 12V
  • Power Consumption:  < 10W
  • Operating Temperature:  -4°F ~ 158°F (-20°C ~ 70°C)
  • Storage Temperature:  -22°F ~ 176°F (-30°C ~ 80°C)
  • Dimension (mm):  196W x 121.5H x 35D
  • Weight (lb):  1.54
  • FCC, CE, E13 Certification
  • ROHS Compliant
  • Supports HDCP
  • 24 Month Warranty
  • 30 days No dead Pixel Guarantee
