Description
AsteRx-m2 UAS RTK Receiver by Septentrio is a GNSS receiver specifically designed for straightforward integration into UAS applications providing centimeter-level RTK positioning at less than 1W (GPS and GLONASS L1/L2). It features standard connections to Pixhawk and ArduPilot and a wide range 6-30 V power input as well as an event marker input to accurately time stamp shutter events.
Key Features
- Multi-constellation, multi-frequency all-in-view satellite tracking
- Centimeter-level RTK position accuracy with or without a real-time datalink
- AIM+ anti-jamming and monitoring system
- Camera shutter synchronization
- Plug compatible with Pixhawk and ArduPilot
Designed for UAS
The AsteRx-m2 UAS is designed for easy integration into any system. Standard connectors directly to your autopilot (e.g. Pixhawk) and the wide 6-30 V input power range allows you to use the power directly from the vehicle power bus. Event markers can accurately synchronize a camera shutter with GNSS time. The command interface is fully open and an SDK is provided to help create professional custom applications.
Interference Robustness
The AsteRx-m2 UAS features AIM+, the most advanced on-board anti-jamming technology on the market. It can suppress the widest variety of interferers, from simple continuous narrowband signals to the most complex wideband and pulsed jammers. The RF spectrum can be viewed in real-time in both time and frequency domains.
No need for ground control points
The AsteRx-m2 UAS works seamlessly with GeoTagZ Software and its SDK library for RPK (ReProcessed Kinematic) offline processing. This give RTK accuracy without the need for Ground Control Points or a real-time datalink.
Ultra-low power design
The AsteRx-m2 UAS provides RTK positioning at the lowest power consumption of any comparable device on the market. This means longer operation on a single battery charge, smaller batteries and greater usability.
About Septentrio
Septentrio designs, manufactures and sells highly accurate GPS/GNSS receivers for demanding applications requiring accuracies in the decimeter or centimeter range — even under difficult conditions. Whether it’s on the high sea, in scintillation prone areas or at high latitudes, our customers know that Septentrio receivers deliver fast, accurate and reliable positions. In urban canyons, under canopies or even under circumstances where there is deliberate interference, our receivers make our customers excel.
