Description
AsteRx-m2 is a compact, high-performance, ultra-low power, GNSS receiver. It is ideal for applications where power and space are at a premium — integration into UAS, mobile platforms and others.
It incorporates the latest in anti-jamming technology and sets the standard for reliability and power consumption.
Key Features
- Best-in-class reliable and scalable position accuracy
- AIM + anti-jamming and monitoring system
- Industry-leading, ultra-low power consumption
- All-in-view multi-constellation, multi-frequency satellite tacking
- Easy integration
Feature Rich
The GNSS+ toolset means the AsteRx-m2 comes into its own in difficult conditions:
- LOCK+ for robust tracking during high vibrations and shocks
- APME+ disentangles direct signals and those reflected from nearby structures
- IONO+ provides advanced protection agains ionospheric disturbance
AsteRx-m2 also features time synchronization for high-precision timing applications and L-Band tracking for PPP positioning using SECORX. Two electronically identical antenna connectors support both passive and active antennas.
Interference Robustness
The AsteRx-m2 features AIM+, the most advanced on-board, anti-jamming technology on the market. It can suppress the widest variety of interference — from simple continuous narrow-band signals to the most complex wide-band and pulsed jammers. The RF spectrum can be viewed in real-time in both time and frequency domains.
Ultra-low Power Design
It provides RTK positioning at the lowest power consumption of any comparable device on the market. This means longer operation on a single battery charge, smaller batteries and greater usability.
Easy Integration
The AsteRx-m2 comes with fully-documented interfaces, commands and data messages. The included RxTools software allows receiver configuration and monitoring as well as data logging and analysis.
An SDK is provided to help integrators create professional custom applications. The AsteRx-m2 is compatible with GeoTagZ Software and its SDK library for PPK (post-processed kinematic) offline processing.
